Mitsubishi Outlander IV (2021-2024) intake air temperature sensor Wiring diagram

This page shows the only wiring diagram for the component.intake air temperature sensor, which is found in the car Mitsubishi Outlander IV (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram intake air temperature sensor (1 of 1)

Wiring diagram intake air temperature sensor for Mitsubishi Outlander IV (2021-2024)

Get access

BLK WIRE BLU/GRN WIRE BLU/YEL WIRE BRN WIRE CONDENSER D-11 GRN WIRE GRY WIRE IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 INTAKE AIR TEMPERATURE SENSOR J/C LT BLU WIRE LT GRN WIRE MASS AIR FLOW SENSOR NCA WIRE ORG/BLU WIRE PNK WIRE PPL/BLU WIRE PPL/GRN WIRE PPL/LT BLU WIRE PPL/LT GRN WIRE PPL/RED WIRE PPL/WHT WIRE PPL/YEL WIRE RED WIRE SPARK PLUG VIO WIRE WHT WIRE WHT/BLU WIRE YEL WIRE

Go to component: -> Wiring diagram engine performance 2.5l (7 of 8) -> INTAKE AIR TEMPERATURE SENSOR
