Mitsubishi Outlander IV (2021-2024) inside rear view mirror assembly Wiring diagrams
This page contains all the electrical diagrams for the component. inside rear view mirror assembly, in which he is found in the car Mitsubishi Outlander IV (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
inside rear view mirror assembly wiring diagram (1 of 3)
A-09
A-36
A-42
A-45
A-51
A-71
ADAS CONTROL UNIT
BACK DOOR OPENER SWITCH ASSEMBLY
BLK WIRE
C-78
D-04
D-37
D-79
DISTANCE SENSOR
E-04
E-06
E-13
E-14
ELECTRICAL PARKING BRAKE ACTUATOR
EPS-ECU
G-18
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HEADLIGHT WASHER MOTOR
HORN (LOW)
INSIDE REAR VIEW MIRROR ASSEMBLY
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
J/C 36 (E-15)
LANE CAMERA UNIT
LEFT FRONT COMBINATION LIGHT
LEFT FRONT FOG LIGHT
LEFT FRONT SEAT HEATER
LEFT HEADLIGHT ASSEMBLY
LEFT VANITY MIRROR LIGHT
MAP LAMP ASSEMBLY
PPL/BRN WIRE
PTC HEATER
REAR WINDOW DEFOGGER
RIGHT VANITY MIRROR LIGHT
ROOM LAMP
SUNROOF MOTOR ASSEMBLY,
SUNROOF SWITCH
WASHER MOTOR
Go to component -> Ground distribution circuit (5 of 5) -> INSIDE REAR VIEW MIRROR ASSEMBLY
inside rear view mirror assembly wiring diagram (2 of 3)
Go to component -> Inside rear view mirror circuit -> INSIDE REAR VIEW MIRROR ASSEMBLY
inside rear view mirror assembly wiring diagram (3 of 3)
A-76
A-78
A-81
A-82
A/C CONTROLLER ASSEMBLY
ADAS CONTROL UNIT
AIR BAG DIAGNOSIS SENSOR UNIT
BCM (BODY CONTROL MODULE)
BLU WIRE
BRN WIRE
C-09
C-12
C-13
C-19
C-44
C-46
C-61
C-74
C-79
CAMERA CONTROL UNIT
CHASSIS CONTROL MODULE
CLOCKSPRING
COMBINATION METER
D-04
D-12
D-14
D-15
D-16
D-17
D-18
D-37
D-40
D-62
D-90
DISTANCE SENSOR
DRIVER'S SIDE FRONT DOOR LOCK ACTUATOR
ETACS-ECU
F-27
FROM BATTERY TERMINAL W/ FUSIBLE LINK (DIAGRAM 1 OF 6)
FROM FUSE 31 (DIAGRAM 1 OF 6)
FRONT CAMERA UNIT
FRONT POWER WINDOW SUB SWITCH
FUSE 1
FUSE 10
FUSE 4
FUSE 40
FUSE 49
FUSE 5
FUSE 51
FUSE 6
FUSE 9
GATEWAY ECU
GRN WIRE
GRY WIRE
IGNITION RELAY 1
INSIDE REAR VIEW MIRROR ASSEMBLY
J/C 19 (D-10)
J/C 20 (D-19)
LEFT REAR WHEEL SENSOR
LEFT SIDE RADAR
LT BLU WIRE
LT GRN WIRE
OCCUPANT SENSOR
PNK WIRE
PPL/BLU WIRE
PPL/BRN WIRE
PPL/GRN WIRE
PPL/RED WIRE
PPL/WHT WIRE
PPL/YEL WIRE
PTC HEATER RELAY 1
PTC HEATER RELAY 2
PTC HEATER RELAY 3
REAR WINDOW DEFOGGER RELAY
RED WIRE
SELECTOR LEVER ASSEMBLY
SHIFT ACTUATOR RELAY A
SONAR CONTROL UNIT
STEERING HEATER RELAY
STEERING SWITCH
STEERING WHEEL SENSOR
TO WIRELESS CHARGER UNIT (DIAGRAM 6 OF 6)
VIO/PNK WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 6) -> INSIDE REAR VIEW MIRROR ASSEMBLY
