Mitsubishi Outlander IV (2021-2024) heated steering wheel Wiring diagrams

This page contains all the electrical diagrams for the component. heated steering wheel, in which he is found in the car Mitsubishi Outlander IV (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram heated steering wheel (1 of 2)

Wiring diagram heated steering wheel for Mitsubishi Outlander IV (2021-2024)

Get access

A-75 A-76 A/C CONTROLLER ASSEMBLY ACCESSORY SOCKET (REAR FLOOR CONSOLE) ADAS OFF SWITCH AIR BAG DIAGNOSIS SENSOR UNIT AUXILIARY INPUT JACKS BLK WIRE BLOWER MOTOR C-01 C-07 C-19 C-44 C-46 C-61 C-72 C-79 CLOCKSPRING COMBINATION METER DATA LINK CONNECTOR GATEWAY ECU HEATED STEERING WHEEL HUD HUD SWITCH ILLUMINATION CONTROL SWITCH J/C 10 (C-37) J/C 13 (C-56) J/C 17 (C-87) J/C 19 (D-10) J/C 7 (C-11) J/C 9 (C-36) KEYLESS OPERATION CONTROL UNIT LEFT FRONT, REAR HEATED SEAT SWITCH LIFTGATE LATCH LT GRN WIRE NAVI CONTROL UNIT NCA WIRE PARKING BRAKE SWITCH PPL/BLK WIRE REAR USB CHARGE PORT RIGHT FRONT, REAR HEATED SEAT SWITCH S-AWC DRIVE MODE SELECTOR SELECTOR LEVER ASSEMBLY SPARE CONNECTOR (SWITCH BOX) STARTER STEERING SWITCH TELEMATICS CONTROL UNIT (TCU) TELEMATICS CONTROL UNIT (TCU) SHIELD TRANSAXLE CONTROL MODULE WIRELESS CHARGER UNIT

Go to component: -> Ground distribution circuit (3 of 5) -> HEATED STEERING WHEEL

Wiring diagram heated steering wheel (2 of 2)

Wiring diagram heated steering wheel for Mitsubishi Outlander IV (2021-2024)

Get access

A/C CONTROLLER ASSEMBLY BLK WIRE C-12 C-13 C-79 CLOCKSPRING (UNDER STEERING WHEEL) ETACS-ECU FUSE 10 FUSE 40 GRY WIRE HEATED STEERING WHEEL HOT W/ ACCESSORY RELAY ENERGIZED HOT W/ IGNITION RELAY 1 ENERGIZED LT GRN WIRE NCA WIRE STEERING HEATER RELAY TAN WIRE YEL WIRE

Go to component: -> Heated steering wheel circuit -> HEATED STEERING WHEEL
