Mitsubishi Outlander IV (2021-2024) front passenger's side seat belt pretensioner Wiring diagram
This page shows the only wiring diagram for the component.front passenger's side seat belt pretensioner, which is found in the car Mitsubishi Outlander IV (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's side seat belt pretensioner (1 of 1)
AIR BAG DIAGNOSIS SENSOR UNIT
BLK WIRE
BLU WIRE
BRN WIRE
C-53
C-74
CRASH ZONE SENSOR
D-11
D-25
D-28
D-29
D-30
D-47
D-51
D-57
F-05
F-19
FRONT IMPACT SENSOR
FRONT PASSENGER'S SIDE SEAT BELT PRETENSIONER
GRN WIRE
GRY WIRE
J/C 21 (D-22)
J/C 22 (D-23)
LEFT CURTAIN AIR BAG MODULE (SQUIB)
LEFT FRONT DOOR SATELLITE SENSOR
LEFT FRONT SEAT BELT PRETENSIONER
LEFT LAP PRETENSIONER
LEFT REAR OCCUPANT DETECTION UNIT
LEFT REAR SEAT BELT BUCKLE SWITCH
LEFT SIDE AIR BAG MODULE (SQUIB)
LT BLU WIRE
LT GRN WIRE
PNK WIRE
RED WIRE
RIGHT SIDE AIR BAG MODULE (SQUIB)
VIO WIRE
WHT WIRE
YEL WIRE
Go to component: -> Supplemental restraints circuit (1 of 3) -> FRONT PASSENGER'S SIDE SEAT BELT PRETENSIONER
