Mitsubishi Outlander IV (2021-2024) front auxiliary input jacks Wiring diagram
This page shows the only wiring diagram for the component.front auxiliary input jacks, which is found in the car Mitsubishi Outlander IV (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front auxiliary input jacks (1 of 1)
BLK WIRE
BRN WIRE
C-54
CALIBRATION CONNECTOR
CAMERA CONTROL UNIT
COMPUTER DATA LINES SYSTEM
D-114
D-115
D-116
D-12
D-15
D-40
D-61
ETACS-ECU
FRONT AUXILIARY INPUT JACKS
FRONT CAMERA
FUSE 40
HOT W/ ACCESSORY RELAY ENERGIZED
J/C 19 (D-10)
LEFT SIDE CAMERA
LT BLU WIRE
NCA WIRE
PNK WIRE
PPL/GRN WIRE
REAR CAMERA
RED WIRE
RIGHT SIDE CAMERA
SONAR CONTROL UNIT
VIO WIRE
WHT WIRE
YEL WIRE
Go to component: -> All around vision camera circuit -> FRONT AUXILIARY INPUT JACKS
