Mitsubishi Outlander IV (2021-2024) electric intake valve timing control position sensor Wiring diagram

This page shows the only wiring diagram for the component.electric intake valve timing control position sensor, which is found in the car Mitsubishi Outlander IV (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram electric intake valve timing control position sensor (1 of 1)

Wiring diagram electric intake valve timing control position sensor for Mitsubishi Outlander IV (2021-2024)

Get access

A-34 B-12 BLK WIRE BLU WIRE BLU/GRN WIRE BLU/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM ELECTRIC INTAKE VALVE TIMING CONTROL MOTOR ELECTRIC INTAKE VALVE TIMING CONTROL POSITION SENSOR ENGINE CONTROL MODULE FUEL RELAY GRN WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE LT BLU WIRE LT GRN WIRE ORG/BLU WIRE PNK WIRE PPL/LT GRN WIRE RED WIRE SUB + THROTTLE ACTUATOR CONTROL MOTOR THROTTLE POSITION SENSOR VIO WIRE WHT WIRE WHT/BLU WIRE YEL WIRE

Go to component: -> Wiring diagram engine performance 2.5l (5 of 8) -> ELECTRIC INTAKE VALVE TIMING CONTROL POSITION SENSOR
