Mitsubishi Outlander IV (2021-2024) door mirror defogger Wiring diagrams

This page contains all the electrical diagrams for the component. door mirror defogger, in which he is found in the car Mitsubishi Outlander IV (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram door mirror defogger (1 of 2)

Wiring diagram door mirror defogger for Mitsubishi Outlander IV (2021-2024)

Get access

A-46 BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE C-01 C-05 C-12 COMPUTER DATA LINES SYSTEM D-07 D-08 D-12 D-13 D-16 D-18 D-79 DEFOGGER RELAY A DEFOGGER RELAY B DOOR MIRROR DEFOGGER ETACS-ECU FUSE FUSE 10 FUSE 43 G-02 G-18 GRN WIRE HOT AT ALL TIMES J/C 31 (F-04) J/C 32 (F-18) LEFT DOOR MIRROR ASSEMBLY PNK WIRE PPL/BLU WIRE PPL/LT BLU WIRE PPL/RED WIRE PPL/YEL WIRE REAR WINDOW DEFOGGER REAR WINDOW DEFOGGER (LIFTGATE WINDOW GLASS) REAR WINDOW DEFOGGER RELAY RED WIRE RIGHT DOOR MIRROR ASSEMBLY

Go to component: -> Defoggers circuit -> DOOR MIRROR DEFOGGER

Wiring diagram door mirror defogger (2 of 2)

Wiring diagram door mirror defogger for Mitsubishi Outlander IV (2021-2024)

Get access

13 D-12 27 D-18 BLK WIRE BLU WIRE BRN WIRE D-12 D-15 D-18 D-91 DEFOGGER SYSTEM DOOR MIRROR DEFOGGER ETACS-ECU FUSE 45 GRN WIRE GRY WIRE HORIZONTAL MOVEMENT MOTOR HOT W/ ACCESSORY RELAY ENERGIZED J/C 31 (F-04) J/C 32 (F-18) LEFT DOOR MIRROR ASSEMBLY LEFT REAR WHEEL SENSOR LEFT SIDE RADAR LT BLU WIRE LT GRN WIRE PNK WIRE POWER WINDOW MAIN SWITCH PPL/BLU WIRE PPL/GRN WIRE PPL/LT BLU WIRE PPL/YEL WIRE RED WIRE REMOTE CONTROLLED MIRROR SWITCH RIGHT DOOR MIRROR ASSEMBLY TAN WIRE VERTICAL MOVEMENT MOTOR VIO WIRE WHT WIRE YEL WIRE

Go to component: -> Power mirrors circuit -> DOOR MIRROR DEFOGGER
