Mitsubishi Outlander III facelift 3 (2018-2024) water cold temp ind Wiring diagrams
This page contains all the electrical diagrams for the component. water cold temp ind, in which he is found in the car Mitsubishi Outlander III facelift 3 (2018-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram water cold temp ind (1 of 2)
2.4L
3.0L
A/C PRESSURE SENSOR
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
C-126
CAN TRANSCEIVER CIRCUIT
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CONDENSER FAN RELAY
FAN CONTROL RELAY
FIN THERMO SENSOR
GRN WIRE
GRY WIRE
GRY/GRN WIRE
HIGH CONTRAST METER
INTERIOR TEMPERATURE SENSOR
J/C 5 (C-01)
LCD
LED DRIVE CIRCUIT
LT GRN WIRE
NCA WIRE
OUTSIDE/INSIDE SELECTION DAMPER CONTROL MOTOR
PNK WIRE
PNK/BLU WIRE
RADIATOR FAN RELAY
RED WIRE
RED/GRN WIRE
STANDARD METER
VIO WIRE
VIO/GRN WIRE
WATER COLD TEMP IND
WATER HOT TEMP IND
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (2 of 3) -> WATER COLD TEMP IND
Wiring diagram water cold temp ind (2 of 2)
2.4L
3.0L
B-47
B-48
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
C-402
C-416
C-417
CAN DRIVE CIRCUIT
CAN TRANSCEIVER CIRCUIT
CANL B-07
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CONDENSER FAN MOTOR
CONDENSER FAN RELAY
ENGINE COMPARTMENT RELAY BOX
ENGINE CONTROL MODULE
ENGINE COOLANT TEMPERATURE SENSOR
F/HI
FAN CONTROL RELAY
FLO
FUSE 15
GRN WIRE
HIGH CONTRAST METER
HOT AT ALL TIMES
INTERFACE CIRCUIT
LCD (WATER HOT TEMP)
LED DRIVE CIRCUIT
LT GRN WIRE
NCA WIRE
PNK WIRE
RADIATOR FAN MOTOR
RADIATOR FAN RELAY
RED WIRE
RED/GRN WIRE
RELAY ENERGIZED ETACS-ECU
STANDARD METER
WATER COLD TEMP IND
WATER HOT TEMP IND
WHT WIRE
WHT/BLU WIRE
WTS B-06
WTSE
Go to component -> Cooling fan circuit -> WATER COLD TEMP IND
