Mitsubishi Outlander III facelift 3 (2018-2024) w/ paddle shift w/o paddle shift Wiring diagram
This page shows the only wiring diagram for the component.w/ paddle shift w/o paddle shift, which is found in the car Mitsubishi Outlander III facelift 3 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ paddle shift w/o paddle shift (1 of 1)
BLK WIRE
BRN WIRE
C-02
C-03
C-113
C-402
C-419
C-420
C-421
C-422
DASH GROUNDING J/C (C-30)
ETACS-ECU
FUSE 14
FUSE 15
FUSE 22
GRN WIRE
GROUND DISTRIBUTION SYSTEM
GRY WIRE
HOT AT ALL TIMES
HOT W/ ACC RELAY 2 ENERGIZED
J/C 1 (C-02, C-03)
J/C 4 (C-05)
J/C 5 (C-01)
KEY INTERLOCK SOLENOID
KEY LOCK RELAY
LT GRN WIRE
NCA WIRE
P RANGE DETECTION SWITCH
RELAY ENERGIZED
SELECTOR LEVER ASSEMBLY
SHIFT LOCK SOLENOID
SLSO
STOPLIGHT CONTROL CIRCUIT
STOPLIGHT SWITCH
VIO WIRE
W/ PADDLE SHIFT W/O PADDLE SHIFT
W/O KEYLESS ENTRY
WHT WIRE
Go to component -> Shift interlock circuit -> W/ PADDLE SHIFT W/O PADDLE SHIFT
