Mitsubishi Outlander III facelift 3 (2018-2024) variable valve lift control motor Wiring diagram
This page shows the only wiring diagram for the component.variable valve lift control motor, which is found in the car Mitsubishi Outlander III facelift 3 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram variable valve lift control motor (1 of 1)
ACCELERATOR PEDAL POSITION SENSOR
B-19
B-20
BATM
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BRAKE BOOSTER VACUUM SENSOR
BRN WIRE
ENGINE COMPARTMENT RELAY BOX
GRN WIRE
GRY WIRE
HALL SENSOR
HOT AT ALL TIMES
HSE
HSUS
HSVS
HSWS
LCAH
LCAL
LIFT ECU VALVE (RIGHT REAR CORNER OF ENGINE COMPT)
LT GRN WIRE
MAIN
PNK WIRE
PNK/BLK WIRE
RED WIRE
RED/GRN WIRE
SUB +
VARIABLE VALVE LIFT CONTROL MOTOR
VARIABLE VALVE LIFT CONTROL RELAY
VIO WIRE
VLMU
VLMV
VLMW
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 2.4l (2 of 5) -> VARIABLE VALVE LIFT CONTROL MOTOR
