Mitsubishi Outlander III facelift 3 (2018-2024) outside/inside selection damper control motor Wiring diagram
This page shows the only wiring diagram for the component.outside/inside selection damper control motor, which is found in the car Mitsubishi Outlander III facelift 3 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram outside/inside selection damper control motor (1 of 1)
2.4L
3.0L
A/C PRESSURE SENSOR
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
C-126
CAN TRANSCEIVER CIRCUIT
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CONDENSER FAN RELAY
FAN CONTROL RELAY
FIN THERMO SENSOR
GRN WIRE
GRY WIRE
GRY/GRN WIRE
HIGH CONTRAST METER
INTERIOR TEMPERATURE SENSOR
J/C 5 (C-01)
LCD
LED DRIVE CIRCUIT
LT GRN WIRE
NCA WIRE
OUTSIDE/INSIDE SELECTION DAMPER CONTROL MOTOR
PNK WIRE
PNK/BLU WIRE
RADIATOR FAN RELAY
RED WIRE
RED/GRN WIRE
STANDARD METER
VIO WIRE
VIO/GRN WIRE
WATER COLD TEMP IND
WATER HOT TEMP IND
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (2 of 3) -> OUTSIDE/INSIDE SELECTION DAMPER CONTROL MOTOR
