Mitsubishi Outlander III facelift 3 (2018-2024) lumber support motor Wiring diagram
This page shows the only wiring diagram for the component.lumber support motor, which is found in the car Mitsubishi Outlander III facelift 3 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lumber support motor (1 of 1)
BLK WIRE
BLU WIRE
C-24
DOWN
FRONT HEIGHT MOTOR
FRONT HEIGHT SWITCH
FUSIBLE LINK 24
HOT AT ALL TIMES
LEFT POWER SEAT ASSEMBLY
LUMBER SUPPORT MOTOR
LUMBER SUPPORT SWITCH
NCA WIRE
PASSENGER COMPARTMENT RELAY BOX
REAR HEIGHT MOTOR
REAR HEIGHT SWITCH
RECLINING MOTOR
RECLINING SWITCH
RWD
SLIDE MOTOR
SLIDE SWITCH
WHT WIRE
Go to component -> Driver power seat circuit -> LUMBER SUPPORT MOTOR
