Mitsubishi Outlander III facelift 3 (2018-2024) left rear bank heated oxygen sensor Wiring diagram
This page shows the only wiring diagram for the component.left rear bank heated oxygen sensor, which is found in the car Mitsubishi Outlander III facelift 3 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear bank heated oxygen sensor (1 of 1)
ACCELERATOR PEDAL POSITION SENSOR
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/RED WIRE
C-129
C-402
C-410
C-412
C-414
C-419
C-421
ETACS-ECU
FUEL LEVEL SENSOR (MAIN)
FUEL PUMP MODULE (IN FUEL TANK)
FUEL PUMP RELAY
FUEL TANK DIFFERENTIAL PRESSURE SENSOR
FUEL TANK TEMPERATURE SENSOR
FUSE 14
FUSE 15
GRN WIRE
GRY WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION SWITCH
INSTRUMENT CLUSTER SYSTEM
J/C 2 (C-202)
LEFT BANK LINEAR AIR-FUEL RATIO SENSOR
LEFT REAR BANK HEATED OXYGEN SENSOR
LOCK
LT GRN WIRE
MAIN
NCA WIRE
OSS ECU
PNK/BLU WIRE
RED WIRE
RIGHT BANK LINEAR AIR-FUEL RATIO SENSOR
SUB +
VIO WIRE
VIO/GRN WIRE
W/ ONE TOUCH START
W/O ONE TOUCH START
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.0l (2 of 4) -> LEFT REAR BANK HEATED OXYGEN SENSOR
