Mitsubishi Outlander III facelift 3 (2018-2024) column switch Wiring diagram
This page shows the only wiring diagram for the component.column switch, which is found in the car Mitsubishi Outlander III facelift 3 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram column switch (11 of 11)
3.0L
ACCESSORY SOCKET (INSTRUMENT CENTER PANEL)
ACCESSORY SOCKET (REAR FLOOR CONSOLE)
ASC OFF SWITCH
BATTERY
BLIND SPOT WARNING LIGHT
BLIND SPOT WARNING SWITCH
BLK WIRE
BLK/WHT WIRE
C-09
C-109
C-110
C-113
C-162
C-205
C-221
C-253
C-303
C-311
C-313
C-316
C-318
C-403
C-420
CAMERA- ECU
CLOCKSPRING
COLUMN SWITCH
COMBINATION METER
CRUISE CONTROL SWITCH
D-122
DASH GROUNDING J/C (C-30)
DATA LINK CONNECTOR
DRIVE MODE SELECTOR
ELECTRIC PARKING BRAKE ECU
ELECTRIC PARKING BRAKE SWITCH
ELECTRIC STEERING LOCK
ENGINE SWITCH
ETACS-ECU
FCM SWITCH
FLOOR CONSOLE BOX LIGHT
GATEWAY ECU
GLOVE BOX LIGHT
HANDS FREE MODULE
HAZARD WARNING LIGHT SWITCH
HEATED SEAT RELAY
HEATED STEERING WHEEL RELAY
HEATER CONTROLLER ASSEMBLY (A/C-ECU)
J/C 21 (C-166)
J/C 4 (C-05) (BEHIND CENTER OF DASH)
KEY INTERLOCK SOLENOID
KEY REMINDER SWITCH
KOS ECU
LDW SWITCH
LEFT BANK LINEAR AIR-FUEL RATIO SENSOR SHIELD
LEFT DOOR MIRROR ASSEMBLY
LEFT FRONT DOOR LOCK ACTUATOR
LEFT LOCK/ UNLOCK SWITCH
LINEAR AIR-FUEL RATIO SENSOR SHIELD
METER INFORMATION SWITCH
MULTI VISION DISPLAY
NCA WIRE
OSS ECU
P RANGE DETECTION SWITCH
PADDLE SHIFT SWITCH
POWER LIFTGATE MAIN SWITCH
POWER LIFTGATE SWITCH
POWER WINDOW MAIN SWITCH
RADIO, CD PLAYER
REMOTE CONTROLLED MIRROR SWITCH
RIGHT BANK LINEAR AIR-FUEL RATIO SENSOR SHIELD
SELECTOR LEVER ASSEMBLY
SIDE TURN- SIGNAL LIGHT ASSEMBLY
SPARE CONNECTOR (REAR DISPLAY)
STEERING WHEEL)
THROTTTLE POSITON SENSOR SHIELD
USB ADAPTER (FOR CHARGING)
W/O ELECTRIC PARKING BRAKE
W/O PADDLE SHIFT
W/PADDLE SHIFT
Go to component -> Ground distribution circuit (3 of 3) -> COLUMN SWITCH
