Charging circuit for Mitsubishi Outlander III facelift (2014-2015)

61 62 60 B-26 90 91 99 100 98 101 B-27 ALTF ALTL ALTG A-17 BATTERY BATTERY CURRENT SENSOR (NEAR BATTERY) BATTERY TEMPERATURE SENSOR BLK/RED WIRE BLK/YEL WIRE BLU WIRE BRN WIRE C-417 CAN TRANSCEIVER CIRCUIT COMBINATION METER COMPUTER DATA LINES SYSTEM ECB BTS ECBE ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF FUSE 5 ENGINE COMPT) ENGINE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) ETACS-ECU (LEFT END OF DASH) FUSE 12 FUSIBLE LINK 33 FUSIBLE LINK 36 FUSIBLE LINK BOX (ON POSITIVE TERMINAL OF BATTERY) GENERATOR GENERATOR MALFUNCTION IND LIGHT LED DRIVE CIRCUIT GRY WIRE LCD (GENERATOR MALFUNCTION LIGHT) LT BLU WIRE LT GRN WIRE PNK WIRE RED WIRE RELAY ENERGIZED STARTING CIRCUIT VIO WIRE WHT WIRE YEL WIRE
