Mitsubishi Outlander III facelift (2014-2015) w/ hands free interface system w/o hands free interface system Wiring diagrams

This page contains all the electrical diagrams for the component. w/ hands free interface system w/o hands free interface system, in which he is found in the car Mitsubishi Outlander III facelift (2014-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram w/ hands free interface system w/o hands free interface system (1 of 2)

Wiring diagram w/ hands free interface system w/o hands free interface system for Mitsubishi Outlander III facelift (2014-2015) (1 of 2)

Get access

10 11 D-122 8 D-122 AAL+ AAR+ BLK WIRE BLK/BLU WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE C-303 C-311 CAN (+) CH DN CIRCUIT CK-C CLOCK SPRING (UNDER STEERING WHEEL) COMBINATION METER COMPUTER DATA LINES SYSTEM DASH GROUND J/C (C-30) (BEHIND LEFT SIDE OF DASH) GRN WIRE GRN/YEL WIRE GRY WIRE IE- ILL INTERFACE CIRCUIT J/C 2 (C-202) (BEHIND INSTRUMENT CLUSTER) J/C 4 (C-05) (BEHIND CENTER OF DASH) LT GRN WIRE MODE CH UP NAVIGATION SYSTEM NCA WIRE OFF HOOK SPEECH ON HOOK REAR DISPLAY RED WIRE RED/GRN WIRE RED/WHT WIRE RX-C SH-A SH-C SPARE CONNECTOR STEERING WHEEL MULTI-FUNCTION SWITCH TRANSCEIVER/ TX-C USB BOX VIO WIRE VOL DN VOL UP W/ HANDS FREE INTERFACE SYSTEM W/O HANDS FREE INTERFACE SYSTEM WHT WIRE WHT/BLK WIRE YEL WIRE YEL/PNK WIRE

Go to component -> Navigation circuit, without amplifier (3 of 3) -> W/ HANDS FREE INTERFACE SYSTEM W/O HANDS FREE INTERFACE SYSTEM

Wiring diagram w/ hands free interface system w/o hands free interface system (2 of 2)

Wiring diagram w/ hands free interface system w/o hands free interface system for Mitsubishi Outlander III facelift (2014-2015) (2 of 2)

Get access

10 11 D-122 8 D-122 AAL+ AAR+ BLK WIRE BLK/BLU WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE C-303 C-311 CAN (+) CH DN CIRCUIT CK-C CLOCK SPRING (UNDER STEERING WHEEL) COMBINATION METER COMPUTER DATA LINES SYSTEM DASH GROUND J/C (C-30) (BEHIND LEFT SIDE OF DASH) GRN WIRE GRN/YEL WIRE GRY WIRE IE- ILL INTERFACE CIRCUIT J/C 2 (C-202) (BEHIND INSTRUMENT CLUSTER) J/C 4 (C-05) (BEHIND CENTER OF DASH) LT GRN WIRE MODE CH UP NAVIGATION SYSTEM NCA WIRE OFF HOOK SPEECH ON HOOK REAR DISPLAY RED WIRE RED/GRN WIRE RED/WHT WIRE RX-C SH-A SH-C SPARE CONNECTOR STEERING WHEEL MULTI-FUNCTION SWITCH TRANSCEIVER/ TX-C USB BOX VIO WIRE VOL DN VOL UP W/ HANDS FREE INTERFACE SYSTEM W/O HANDS FREE INTERFACE SYSTEM WHT WIRE WHT/BLK WIRE YEL WIRE YEL/PNK WIRE

Go to component -> Radio circuit, with multi-communication system without amplifier (3 of 3) -> W/ HANDS FREE INTERFACE SYSTEM W/O HANDS FREE INTERFACE SYSTEM
