Mitsubishi Outlander III facelift (2014-2015) vlcr afs afse ats canh canl ign gnde Wiring diagram

12 C-129 AIR CONDITIONING SYSTEM COMPUTER DATA LINES SYSTEM ALTG ALTF ALTL APSE APSS BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE BRN/RED WIRE BRN/YEL WIRE C-129 COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM ECB ECBE AC/R FMB BACK ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT) ENGINE CONTROL MODULE (LEFT REAR CORNER OF ENGINE COMPT) EV DIAG GNDB F/PR FPRE F/TM BBPS P/VT BPES FRONT GROUND J/C (A-25) (LEFT FRONT CORNER OF ENGINE COMPT) FUEL TANK DIFFERENTIAL PRESSURE SENSOR (TOP OF FUEL TANK) FUSE 13 FUSE 14 FUSE 15 FUSE FUSE GRN WIRE GRY WIRE GRY/BLK WIRE GRY/RED WIRE INTAKE AIR TEMPERATURE SENSOR J/C 6 (C-28) (LEFT KICK PANEL) LPFL LRL LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE MASS AIRFLOW SENSOR MASS AIRFLOW SENSOR (LEFT REAR OF ENGINE COMPT) MFI RELAY PNK BTS WIRE PNK WIRE PNK/BLU WIRE RED WIRE RSH C/RL STARTING/ CHARGING SYSTEM STARTING/CHARGING SYSTEM STARTING/CHARGING SYSTEM STARTING/CHARGING SYSTEM STOPLIGHT SWITCH (ABOVE BRAKE PEDAL, ON BRACKET) STRL CNTS BRK PNK WIRE SW- FP/R VIO WIRE VIO/GRN WIRE VIO/RED WIRE VLCR AFS AFSE ATS CANH CANL IGN GNDE WHT WIRE WHT/BLK WIRE YEL WIRE
