Mitsubishi Outlander III facelift (2014-2015) transaxle control module (behind left side Wiring diagram
This page shows the only wiring diagram for the component.transaxle control module (behind left side, which is found in the car Mitsubishi Outlander III facelift (2014-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transaxle control module (behind left side (1 of 1)
12 25 12 25 C-131 32
14 A-107 9 A-108
16 A-108 12 A-107
21 C-138 34 C-130 INHN
48 C-130 4 5
5 A-106
A-107
A/T CONTROL RELAY (A/T) CVT CONTROL RELAY (CVT) (IN ENGINE ROOM RELAY BOX)
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
CAN TRANSCEIVER CIRCUIT
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CRUISE IND (W/ STANDARD METER) LED DRIVE CIRCUIT
CVT A/T
DASH GROUND J/C (C-30) (BEHIND LEFT SIDE OF DASH)
FUSE 1
GRY/BLK WIRE
HOT AT ALL TIMES ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT)
INHP
LCD (CRUISE) (W/ HIGH CONTRAST METER)
LT GRN WIRE
LT GRN/BLK WIRE
OF DASH)
OUTPUT SHAFT SPEED SENSOR (TOP RIGHT OF TRANSAXLE)
RED/BLU WIRE
RED/GRN WIRE
SECONDARY PULLEY SPEED SENSOR (TOP OF TRANSAXLE)
SECS 48 C-137 10 11 PGB- SGND
TRANSAXLE CONTROL MODULE (BEHIND LEFT SIDE
TRANSMISSION RANGE SWITCH (TOP OF TRANSAXLE)
TRANSMISSIONS SYSTEM
VIO WIRE
VIO/RED WIRE
WHT WIRE
Go to component -> Cruise control circuit, without adaptive cruise control (2 of 2) -> TRANSAXLE CONTROL MODULE (BEHIND LEFT SIDE
