Mitsubishi Outlander III facelift (2014-2015) shift switch selector lever assembly Wiring diagram

18 C-127 PNK WIRE 3 A-16 6 C-127 A-16 A-17 AUTO MODE SELECT SWITCH BATT INHP INHR INHN MSW SECS PRMS N/R LRPS BLK WIRE BLU WIRE BRN WIRE C-28 C-403 C-410 C-411 C-412 C-417 CAN DRIVE CIRCUIT CIRCUIT INTERFACE CIRCUIT TRANSCEIVER COMBINATION METER COMPUTER DATA LINES SYSTEM CVT ASSEMBLY (IN TRANSMISSION) CVT FAILURE) CVT TEMPERATURE (CVT POSITION LCD ETACS-ECU (LEFT END OF DASH) FUSE FUSE 12 FUSE 18 FUSE 9 GRN WIRE GROUNDING CONNECTOR (C-01) GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT) FUSE 3 ILL INTERFACE CIRCUIT INTERIOR LIGHTS SYSTEM GROUNDING CONNECTOR (C-01) LINE PRESSURE SOLENOID VALVE LOCK-UP SELECTION SOLENOID VALVE LOCK-UP SOLENOID VALVE ROM-ASSEMBLY LT BLU WIRE LT GRN WIRE NCA WIRE PADDLE SHIFT SWITCH (IF EQUIPPED) PDDW PDUP PNK 15 14 WIRE PNK LUOS WIRE PNK WIRE PRIMARY PULLEY SPEED SENSOR (ON TRANSAXLE) RED WIRE SECONDARY PRESSURE SOLENOID VALVE SECONDARY PULLEY SPEED SENSOR (TOP OF TRANSAXLE) SECONDARY TRANSMISSION FLUID PRESSURE SENSOR SGND SSPW SPWR SHIFT SWITCH SELECTOR LEVER ASSEMBLY SPORT MODE STARTING/ CHARGING SYSTEM STEPPER MOTOR STOPLIGHT SWITCH TRANSAXLE CONTROL MODULE (LEFT END OF DASH) TRANSMISSION FLUID TEMPERATURE SENSOR TRANSMISSION RANGE SWITCH (TOP OF TRANSAXLE) UPSW DWSW INHD PNK WIRE VIO WIRE WHT WIRE YEL WIRE
