Mitsubishi Outlander III facelift (2014-2015) orre lpfl lrl Wiring diagram

12 C-129 A-106 AC/R FMB BACK AFS AFSE ATS CANH CANL IGN GNDE AIR CONDITIONING SYSTEM COMPUTER DATA LINES SYSTEM APSE APSS BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE BRN/RED WIRE BRN/YEL WIRE C-129 COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM D-138 ENGINE CONTROL MODULE (LEFT REAR CORNER OF ENGINE COMPT) EV DIAG GNDB EVAPORATIVE EMISSION VENTILATION SOLENOID (REAR OF ENGINE COMPT) F/PR FPRE F/TM FRONT GROUND J/C (A-25) (LEFT FRONT CORNER OF ENGINE COMPT) FUSE 13 FUSE 15 FUSE 14 FUSE FUSE GRN WIRE GRY WIRE GRY/BLK WIRE GRY/RED WIRE INTAKE AIR TEMPERATURE SENSOR J/C 6 (C-28) (LEFT KICK PANEL) LPFR ALTG ALTF ALTL LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE MASS AIRFLOW SENSOR MASS AIRFLOW SENSOR (LEFT REAR OF ENGINE COMPT) MFI RELAY NCA WIRE ORRE LPFL LRL P/VT PNK WIRE PNK/BLU WIRE RED WIRE RELAY BOX (LEFT SIDE OF ENGINE COMPT) RSH C/RL STARTING/ CHARGING SYSTEM STARTING/CHARGING SYSTEM STOPLIGHT SWITCH (ABOVE BRAKE PEDAL, ON BRACKET) STRL CNTS BRK PNK WIRE SW- FP/R VIO WIRE VIO/GRN WIRE VIO/RED WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
