Mitsubishi Outlander III facelift (2014-2015) on off hook hook Wiring diagrams

This page contains all the electrical diagrams for the component. on off hook hook, in which he is found in the car Mitsubishi Outlander III facelift (2014-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram on off hook hook (1 of 6)

Wiring diagram on off hook hook for Mitsubishi Outlander III facelift (2014-2015) (1 of 6)

Get access

21 11 22 9 10 C-17 BLK WIRE BLU WIRE BRN WIRE C-304 3 C-312 CH DN VOL UP CH UP CLOCK SPRING (UNDER STEERING WHEEL) COMBINATION METER COMPUTER DATA LINES SYSTEM GRN WIRE GROUNDING CONNECTOR (C-01) GRY WIRE ILL INTERFACE CAN TRANSCEIVER CIRCUIT CIRCUIT J/C 2 (C-04) (LEFT SIDE OF DASH) LT BLU WIRE LT GRN WIRE MODE ON OFF HOOK HOOK PNK WIRE RED WIRE SPEECH STEERING WHEEL MULTI-FUNCTION SWITCH VIO WIRE VOL DN WHT WIRE YEL WIRE

Go to component -> Navigation circuit, with amplifier (2 of 3) -> ON OFF HOOK HOOK

Wiring diagram on off hook hook (2 of 6)

Wiring diagram on off hook hook for Mitsubishi Outlander III facelift (2014-2015) (2 of 6)

Get access

21 11 22 9 10 C-17 BLK WIRE BLU WIRE BRN WIRE C-17 C-212 C-225 C-26 C-304 3 C-312 CH DN VOL UP CH UP CLOCK SPRING (UNDER STEERING WHEEL) COMBINATION METER COMPUTER DATA LINES SYSTEM F-21 F-22 GRN WIRE GROUNDING CONNECTOR (C-01) GRY WIRE ILL INTERFACE CAN TRANSCEIVER CIRCUIT CIRCUIT J/C 2 (C-104) LEFT FRONT LEFT DOOR TWEETER SPEAKER LEFT REAR DOOR SPEAKER LT BLU WIRE LT GRN WIRE MODE ON OFF HOOK HOOK PNK WIRE RED WIRE RIGHT FRONT DOOR SPEAKER RIGHT REAR DOOR SPEAKER RIGHT TWEETER SPEECH STEERING WHEEL MULTI-FUNCTION SWITCH VIO WIRE VOL DN WHT WIRE YEL WIRE

Go to component -> Navigation circuit, without amplifier (2 of 2) -> ON OFF HOOK HOOK

Wiring diagram on off hook hook (3 of 6)

Wiring diagram on off hook hook for Mitsubishi Outlander III facelift (2014-2015) (3 of 6)

Get access

21 11 22 9 10 C-17 BLK WIRE BLU WIRE BRN WIRE C-304 3 C-312 CH DN VOL UP CH UP CLOCK SPRING (UNDER STEERING WHEEL) COMBINATION METER COMPUTER DATA LINES SYSTEM GRN WIRE GROUNDING CONNECTOR (C-01) GRY WIRE ILL INTERFACE CAN TRANSCEIVER CIRCUIT CIRCUIT J/C 2 (C-04) (LEFT SIDE OF DASH) LT BLU WIRE LT GRN WIRE MODE ON OFF HOOK HOOK PNK WIRE RED WIRE SPEECH STEERING WHEEL MULTI-FUNCTION SWITCH VIO WIRE VOL DN WHT WIRE YEL WIRE

Go to component -> Radio circuit, with multi-communication system with amplifier (2 of 3) -> ON OFF HOOK HOOK

Wiring diagram on off hook hook (4 of 6)

Wiring diagram on off hook hook for Mitsubishi Outlander III facelift (2014-2015) (4 of 6)

Get access

21 11 22 9 10 C-17 BLK WIRE BLU WIRE BRN WIRE C-17 C-212 C-225 C-26 C-304 3 C-312 CH DN VOL UP CH UP CLOCK SPRING (UNDER STEERING WHEEL) COMBINATION METER COMPUTER DATA LINES SYSTEM F-21 F-22 GRN WIRE GROUNDING CONNECTOR (C-01) GRY WIRE ILL INTERFACE CAN TRANSCEIVER CIRCUIT CIRCUIT J/C 2 (C-104) LEFT FRONT LEFT DOOR TWEETER SPEAKER LEFT REAR DOOR SPEAKER LT BLU WIRE LT GRN WIRE MODE ON OFF HOOK HOOK PNK WIRE RED WIRE RIGHT FRONT DOOR SPEAKER RIGHT REAR DOOR SPEAKER RIGHT TWEETER SPEECH STEERING WHEEL MULTI-FUNCTION SWITCH VIO WIRE VOL DN WHT WIRE YEL WIRE

Go to component -> Radio circuit, with multi-communication system without amplifier (2 of 2) -> ON OFF HOOK HOOK

Wiring diagram on off hook hook (5 of 6)

Wiring diagram on off hook hook for Mitsubishi Outlander III facelift (2014-2015) (5 of 6)

Get access

1 2 3 4 PNK WIRE BLK WIRE BLU WIRE BRN WIRE C-135 C-226 C-304 3 C-312 CH DN VOL UP CH UP CLOCK SPRING (UNDER STEERING WHEEL) COMBINATION METER COMPUTER DATA LINES SYSTEM GRN WIRE GROUNDING CONNECTOR (C-01) GRY WIRE ILL INTERFACE CAN TRANSCEIVER CIRCUIT CIRCUIT J/C 2 (C-04) (LEFT SIDE OF DASH) LT BLU WIRE LT GRN WIRE MODE ON OFF HOOK HOOK PNK WIRE RED WIRE SPEECH STEERING WHEEL MULTI-FUNCTION SWITCH VIO WIRE VOL DN WHT WIRE

Go to component -> Radio circuit, without multi-communication system with amplifier (2 of 3) -> ON OFF HOOK HOOK

Wiring diagram on off hook hook (6 of 6)

Wiring diagram on off hook hook for Mitsubishi Outlander III facelift (2014-2015) (6 of 6)

Get access

1 2 3 PNK WIRE BLK WIRE BLU WIRE BRN WIRE C-135 C-17 C-212 C-225 C-226 C-26 C-304 3 C-312 CH DN VOL UP CH UP CLOCK SPRING (UNDER STEERING WHEEL) COMBINATION METER COMPUTER DATA LINES SYSTEM F-21 F-22 GRN WIRE GROUNDING CONNECTOR (C-01) GRY WIRE ILL INTERFACE CAN TRANSCEIVER CIRCUIT CIRCUIT J/C 2 (C-04) (LEFT SIDE OF DASH) LEFT FRONT DOOR SPEAKER LEFT REAR DOOR SPEAKER LEFT TWEETER LT GRN WIRE MODE ON OFF HOOK HOOK PNK WIRE RED WIRE RIGHT FRONT DOOR SPEAKER RIGHT REAR DOOR SPEAKER RIGHT TWEETER SPEECH STEERING WHEEL MULTI-FUNCTION SWITCH VIO WIRE VOL DN WHT WIRE YEL WIRE

Go to component -> Radio circuit, without multi-communication system without amplifier (2 of 2) -> ON OFF HOOK HOOK
