Mitsubishi Outlander III facelift (2014-2015) on hook Wiring diagrams

This page contains all the electrical diagrams for the component. on hook, in which he is found in the car Mitsubishi Outlander III facelift (2014-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram on hook (1 of 3)

Wiring diagram on hook for Mitsubishi Outlander III facelift (2014-2015) (1 of 3)

Get access

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 B(+) 17 18 19 20 21 22 23 24 25 26 27 28 GND 18 9 4 3 12 C-105 22 32 PNK WIRE BLK WIRE BLU WIRE BRN WIRE C-103 C-135 C-226 C-304 C-312 C-417 CLOCK SPRING (UNDER STEERING WHEEL) ETACS-ECU (LEFT END FUSE OF DASH) GRN WIRE GRY WIRE HANDS FREE MODULE (CENTER OF DASH) HOT AT ALL TIMES J/C 1 (C-231) (LEFT SIDE OF DASH) J/C 3 (C-102) (CENTER OF DASH) LT BLU WIRE MIC - MICROPHONE UNIT (CENTER FRONT OF ROOF) MODE CH UP DOWN NCA WIRE ON HOOK OUTL OUTR SH-A PNK 4 15 WIRE PNK WIRE RADIO, CD PLAYER RED WIRE SH-M MIC- SOUND SYSTEMS SPEECH OFF HOOK STEERING WHEEL MULTI-FUNCTION SWITCH USB ADAPTER USB CABLE VIO WIRE VOL UP VOL DOWN WHT WIRE YEL WIRE

Go to component -> Hands free module circuit, without multi-communication system -> ON HOOK

Wiring diagram on hook (2 of 3)

Wiring diagram on hook for Mitsubishi Outlander III facelift (2014-2015) (2 of 3)

Get access

10 11 D-122 8 D-122 AAL+ AAR+ BLK WIRE BLK/BLU WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE C-303 C-311 CAN (+) CH DN CIRCUIT CK-C CLOCK SPRING (UNDER STEERING WHEEL) COMBINATION METER COMPUTER DATA LINES SYSTEM DASH GROUND J/C (C-30) (BEHIND LEFT SIDE OF DASH) GRN WIRE GRN/YEL WIRE GRY WIRE IE- ILL INTERFACE CIRCUIT J/C 2 (C-202) (BEHIND INSTRUMENT CLUSTER) J/C 4 (C-05) (BEHIND CENTER OF DASH) LT GRN WIRE MODE CH UP NAVIGATION SYSTEM NCA WIRE OFF HOOK SPEECH ON HOOK REAR DISPLAY RED WIRE RED/GRN WIRE RED/WHT WIRE RX-C SH-A SH-C SPARE CONNECTOR STEERING WHEEL MULTI-FUNCTION SWITCH TRANSCEIVER/ TX-C USB BOX VIO WIRE VOL DN VOL UP W/ HANDS FREE INTERFACE SYSTEM W/O HANDS FREE INTERFACE SYSTEM WHT WIRE WHT/BLK WIRE YEL WIRE YEL/PNK WIRE

Go to component -> Navigation circuit, without amplifier (3 of 3) -> ON HOOK
