Mitsubishi Outlander III facelift (2014-2015) engine computer controls data system lines system Wiring diagram
This page shows the only wiring diagram for the component.engine computer controls data system lines system, which is found in the car Mitsubishi Outlander III facelift (2014-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine computer controls data system lines system (1 of 1)
2 15 19 29 32 7 10 23 SGND PGND
BATTERY
BLK WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
C-129
C-403
C-408
C-412
C-415
C-416
C-417
DEFOGGER SYSTEM
ELECTRONIC POWER STEERING SYSTEM
ENGINE COMPUTER CONTROLS DATA SYSTEM LINES SYSTEM
ENGINE SWITCH
ETACS-ECU
FROM ETACS-ECU (DIAGRAM 1 OF 2)
FUSE 10 FUSE 5
FUSE 11 FUSE 4
FUSE 12
FUSE 14
FUSE 17 FUSE 2
FUSE 18
FUSE 24
FUSE 25
FUSIBLE FUSE 15 LINK 20
FUSIBLE LINK 21
FUSIBLE LINK 33
FUSIBLE LINK 34
FUSIBLE LINK 35
FUSIBLE LINK 36
FUSIBLE LINK 37
FUSIBLE LINK BOX (ON POSITIVE TERMINAL OF BATTERY)
GRN WIRE
GROUNDING CONNECTOR
GRY WIRE
HEADLIGHT BACKUP CIRCUIT
IGNITION CONTROL CIRCUIT
IGNITION SWITCH
JOINT CONNECTOR (C-04) (LEFT SIDE OF DASH)
LOCK
LT BLU WIRE
LT GRN WIRE
ON ON
OSS ECU (W/ KEYLESS ENTRY) (RIGHT SIDE OF DASH)
PASSENGER COMPARTMENT RELAY BOX
PNK WIRE
POWER TOPS POWER SYSTEM WINDOWS SYSTEM
POWER WINDOW RELAY
RED WIRE
RELAY
RELAY 3
SEATS SYSTEM
STARTING/ CHARGING SYSTEM
STO
TAILLIGHT CONTROL CIRCUIT
TO ENGINE COMPARTMENT RELAY BOX (DIAGRAM 2 OF 2)
TO ETACS-ECU (DIAGRAM 2 OF 2)
TO IGNITION SWITCH (DIAGRAM 1 OF 2)
TRANSMISSIONS SYSTEM
TRANSMISSIONS, SUPPLEMENTAL RESTRAINTS, ANTI-LOCK BRAKES SYSTEMS
TURN-SIGNAL LIGHT CONTROL CIRCUIT FUEL PUMP RELAY
VIO WIRE
W/ KEYLESS ENTRY
W/O KEYLESS ENTRY
WHT WIRE
WIPER/WASHER SYSTEM
YEL WIRE
Go to component -> Power distribution circuit (1 of 2) -> ENGINE COMPUTER CONTROLS DATA SYSTEM LINES SYSTEM
