Mitsubishi Outlander III facelift (2014-2015) 4 3 2 1 ig canl canh gnd Wiring diagram
This page shows the only wiring diagram for the component.4 3 2 1 ig canl canh gnd, which is found in the car Mitsubishi Outlander III facelift (2014-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 4 3 2 1 ig canl canh gnd (1 of 1)
4 3 2 1 IG CANL CANH GND
BLK WIRE
BRN/BLK WIRE
C-417
CAN DRIVE CIRCUIT
CAN TRANSCEIVER CIRCUIT
CNMH
CNML
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DASH GROUND J/C (C-30) (BEHIND LEFT SIDE OF DASH)
ETACS-ECU (BEHIND LEFT SIDE OF DASH)
FUSE 15
GRY/RED WIRE
INTERFACE CIRCUIT
LCD (LDW DISPLAY)
LDW SWITCH
LDW-ECU (FORWARD OF INSIDE REARVIEW MIRROR)
LDWS
LT GRN WIRE
PNK/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RELAY ENERGIZED
WHT WIRE
YEL/PNK WIRE
Go to component -> Lane departure warning circuit -> 4 3 2 1 IG CANL CANH GND
