Mitsubishi Outlander III facelift (2014-2015) 11 c-410 19 c-415 Wiring diagram
This page shows the only wiring diagram for the component.11 c-410 19 c-415, which is found in the car Mitsubishi Outlander III facelift (2014-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 11 c-410 19 c-415 (1 of 1)
11 C-410 19 C-415
C-304
C-312 CLOCK SPRING (UNDER STEERING WHEEL)
ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT)
ETACS-ECU (LEFT END OF DASH)
FUSE 4
GRN WIRE
HORN (HIGH) (RIGHT FRONT OF ENGINE COMPT)
HORN (LOW) (LEFT FRONT OF ENGINE COMPT)
HORN RELAY
HORN SWITCH
HOT AT ALL TIMES
LT BLU WIRE
VIO WIRE
YEL WIRE
Go to component -> Horn circuit -> 11 C-410 19 C-415
