Mitsubishi Outlander III facelift (2014-2015) 10 c-403 room Wiring diagram
This page shows the only wiring diagram for the component.10 c-403 room, which is found in the car Mitsubishi Outlander III facelift (2014-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 10 c-403 room (1 of 1)
1 C-405
10 11 20 9 C-415 DAS DRH DLH DDR
10 C-403 ROOM
14 C-417
17 16 19 C-416 HORN N-HU HOOD
17 C-417
A-02
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BRN WIRE
C-417
CAN DRIVE CIRCUIT
COMPUTER DATA LINES SYSTEM
D-111
ETACS-ECU (BEHIND LEFT SIDE OF DASH)
FUSE 18
FUSE, RELAY BOX (LEFT SIDE OF ENGINE COMPT)
GRY/BLK WIRE
GRY/GRN WIRE
GRY/RED WIRE
HORNS SYSTEM
HOT AT ALL TIMES
INTERFACE CIRCUIT
J/C 5 (C-01) (BEHIND LEFT SIDE OF DASH)
LEFT FRONT DOOR SWITCH (IN LEFT "B" PILLAR)
LEFT REAR DOOR SWITCH (IN LEFT "C" PILLAR)
LIN DRIVE CIRCUIT
LT GRN WIRE
PNK C-403 5 C-421 PNK WIRE
PNK WIRE
PNK/BLU WIRE
RED WIRE
RED/WHT WIRE
RIGHT FRONT DOOR SWITCH (IN RIGHT "B" PILLAR)
RIGHT REAR DOOR SWITCH (IN RIGHT "C" PILLAR)
SEC
SIGR PWRC GND
TRID C-415
VIO WIRE
WHT/BLK WIRE
YEL WIRE
YEL/PNK WIRE
Go to component -> Forced entry circuit (1 of 2) -> 10 C-403 ROOM
