Mitsubishi Outlander III facelift 2 (2015-2018) door mirror fold relay Wiring diagrams
This page contains all the electrical diagrams for the component. door mirror fold relay, in which he is found in the car Mitsubishi Outlander III facelift 2 (2015-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
door mirror fold relay wiring diagram (1 of 2)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
C-210
C-222
C-403
C-417
CONTROL CIRCUIT
DOOR MIRROR FOLD RELAY
DOOR MIRROR UNFOLD RELAY
ETACS-ECU
FOLDING UNFOLDING SWITCH
FUSE 5
HOT AT ALL TIMES
LEFT DOOR MIRROR ASSEMBLY
MRR
NCA WIRE
REMOTE CONTROLLED MIRROR SWITCH
RIGHT DOOR MIRROR ASSEMBLY
UNFOLD/FOLD MOTOR
VIO WIRE
WHT/BLK WIRE
Go to component -> Fold-back mirrors circuit -> DOOR MIRROR FOLD RELAY
door mirror fold relay wiring diagram (2 of 2)
