Mitsubishi Outlander III (2012-2015) pnk 17 pnk 4 Wiring diagram
This page shows the only wiring diagram for the component.pnk 17 pnk 4, which is found in the car Mitsubishi Outlander III (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk 17 pnk 4 (1 of 1)
3 PNK WIRE
BLK WIRE
BLU WIRE
C-212
C-225
C-415
DEFOGGER SYSTEM
DOWN
ETACS-ECU (LEFT END OF DASH)
FUSE 16
GRN WIRE
HEATER
HORIZONTAL
HOT W/ ACC RELAY 2 ENERGIZED
LEFT
LEFT DOOR MIRROR ASSEMBLY
LEFT OFF
LT GRN WIRE
MOTOR
MOVEMENT HORIZONTAL
MOVEMENT MOTOR
NCA WIRE
PNK 17 PNK 4 WIRE
RED WIRE
REMOTE CONTROLLED MIRROR SWITCH
RIGHT
RIGHT DOOR MIRROR ASSEMBLY
VERTICAL MOVEMENT MOTOR
WHT WIRE
YEL WIRE
Go to component -> Power mirror circuit -> PNK 17 PNK 4 WIRE
