Mitsubishi Outlander III (2012-2015) off road Wiring diagram
This page shows the only wiring diagram for the component.off road, which is found in the car Mitsubishi Outlander III (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram off road (1 of 1)
13 14 C-138
3 D-113
6 7 C-138
A-13
AWC-ECU
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
C-31
C-311
C-313
C-317
C-32
C-33
C-42
CENTER ELECTRONIC CONTROL COUPLING SOLENOID (ON TRANSFER CASE)
COMPUTER DATA LINES SYSTEM
ETACS-ECU (LEFT SIDE OF DASH)
FRONT ELECTRONIC CONTROL COUPLING SOLENOID (ON TRANSFER CASE)
FUSE 12
FUSE 8
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
ILL
LT GRN WIRE
NCA WIRE
NORMAL
OFF ROAD
PNK WIRE
RED/YEL WIRE
RELAY ENERGIZED
S-AWC CONTROL MODE SELECTOR
SNOW
SUPPLEMENTAL RESTRAINTS SYSTEM
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit (3 of 3) -> OFF ROAD
