Mitsubishi Outlander III (2012-2015) fog ind beam ind Wiring diagram

1 C-411 5 C-417 5 A-52 BLK WIRE BLU WIRE BRN WIRE C-127 C-226 C-26 C-410 CAN TRANSCEIVER CIRCUIT CIRCUIT CAN DRIVE CIRCUIT HEADLIGHT BACKUP CIRCUIT INTERFACE COMBINATION METER COMPUTER DATA LINES SYSTEM DAYTIME RUNNING LIGHT RELAY (IN ENG ROOM RELAY BOX) ETACS-ECU (LEFT END OF DASH) FIELD-EFFECT TRANSISTOR FOG IND BEAM IND FOG LIGHT RELAY (IN ENG ROOM RELAY BOX) FUSE 1 FUSE 12 FUSE 13 FUSE 14 FUSE 15 FUSE 18 FUSE 19 FUSE 8 FUSIBLE LINK 36 FUSIBLE LINK BOX (ON POSITIVE TERMINAL OF BATTERY) GRN WIRE GROUNDING CONNECTOR GRY WIRE HEADLIGHT RELAY (HIGH) HEADLIGHT RELAY (LOW) HOT AT ALL TIMES HOT AT ALL TIMES ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT) IGNITION CONTROL CIRCUIT INTERFACE CIRCUIT J/C 3 (C-102) (CENTER OF DASH) LED DRIVE CIRCUIT LEFT FRONT DOOR SWITCH (LEFT "B" PILLAR) LIN DRIVE CIRCUIT LT BLU WIRE LT GRN WIRE NOT USED OFF PARKING BRAKE SWITCH (BASE OF PARKING BRAKE LEVER) PNK 4 C-411 1 C-416 16 C-412 WIRE PNK PNK WIRE PNK WIRE RED WIRE RELAY ENERGIZED VIO WIRE W/ DRL W/O DRL WHT WIRE YEL WIRE
