Mitsubishi Outlander III (2012-2015) driver's door lock door unlock relay relay Wiring diagram
This page shows the only wiring diagram for the component.driver's door lock door unlock relay relay, which is found in the car Mitsubishi Outlander III (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's door lock door unlock relay relay (1 of 1)
A/C COMPRESSOR RELAY
ACCESSORY SOCKET (+) (+) (FRONT FLOOR (-) (-) CONSOLE)
ACCESSORY SOCKET (REAR FLOOR CONSOLE)
AIR CONDITIONING, COOLING FANS SYSTEMS
ANTI-THEFT SYSTEM
BLK WIRE
BLK/GRY WIRE
BLOWER RELAY
BLU WIRE
BRN WIRE
C-403
C-406
C-408
C-415
C-417
CONDENSER FAN RELAY
DOOR UNLOCK RELAY
DRIVER'S DOOR LOCK DOOR UNLOCK RELAY RELAY
ENGINE ANTI-THEFT ANTI-LOCK CONTROLS SYSTEM BRAKES SYSTEM SYSTEM
ENGINE STARTING/ CONTROLS CHARGING SYSTEM SYSTEM
FAN CONTROL RELAY
FOG LIGHT RELAY
FROM FUSIBLE LINK BOX (DIAGRAM 1 OF 2)
FUSE 1
FUSE 13
FUSE 16
FUSE 19
FUSE 2 FUSIBLE LINK 24
FUSE 3
FUSE 3 FUSE 5 FUSE 6
FUSE 30
FUSE 31
FUSE 4
FUSE 6
FUSE 7
FUSE 8 IGNITION CONTROL CIRCUIT
FUSE 9
FUSE 9 FUSE 8 FUSIBLE LINK 26
FUSIBLE LINK 1
FUSIBLE LINK 27
FUSIBLE LINK 28
FUSIBLE LINK 29
GRN WIRE
GROUNDING CONNECTOR
GRY WIRE
HEADLIGHT RELAY (HIGH)
HEADLIGHT RELAY (LOW)
HEADLIGHTS SYSTEM
HORN RELAY
INTERIOR LIGHT CONTROL CIRCUIT
INTERIOR LIGHTS, POWER TOPS SYSTEMS
LIFTGATE UNLOCK RELAY
LT BLU WIRE
LT GRN WIRE
MFI RELAY
PNK WIRE
POWER WINDOW RELAY
RED WIRE
RELAY 2
SOUND SYSTEMS
SOUND, MIRRORS, NAVIGATION, SHIFT INTERLOCK SYSTEMS
STARTING/ TRANSMISSIONS CHARGING SYSTEM SYSTEM
VIO WIRE
WHT WIRE
Go to component -> Power distribution circuit (2 of 2) -> DRIVER'S DOOR LOCK DOOR UNLOCK RELAY RELAY
