Mitsubishi Outlander III (2012-2015) can drive Wiring diagram
This page shows the only wiring diagram for the component.can drive, which is found in the car Mitsubishi Outlander III (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram can drive (1 of 1)
10 6 13 4 C-410
A-52
BEAM IND
BLK WIRE
BLU WIRE
BRN WIRE
C-226
C-26
C-411
C-416 16 C-412
C-417
CAN DRIVE
CAN TRANSCEIVER CIRCUIT
CIRCUIT
CIRCUIT HEADLIGHT BACKUP
CIRCUIT LIN DRIVE
COMBINATION METER
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
DAYTIME RUNNING LIGHT RELAY (IN ENGINE ROOM RELAY BOX)
ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT)
ETACS-ECU (LEFT END OF DASH)
FOG IND
FOG LIGHT RELAY
FUSE 1
FUSE 12
FUSE 13
FUSE 8
GRN WIRE
GROUNDING CONNECTOR
GRY WIRE
HOT AT ALL TIMES
IGNITION CONTROL CIRCUIT
INTERFACE
INTERFACE CIRCUIT
J/C 3 (C-102) (CENTER OF DASH)
LED DRIVE CIRCUIT
LEFT DAYTIME RUNNING LIGHT
LEFT FRONT DOOR SWITCH (LEFT "B" PILLAR)
LIGHTING CONTROL SENSOR (W/ AUTOMATIC LIGHT)
LT BLU WIRE
LT GRN WIRE
OFF
PARKING BRAKE
PNK WIRE
RED WIRE
RELAY ENERGIZED
RIGHT DAYTIME RUNNING LIGHT
SWITCH (BASE OF PARKING BRAKE LEVER)
SYSTEM
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Headlights circuit, with high intensity discharge (1 of 2) -> CAN DRIVE
