Mitsubishi Outlander III (2012-2015) batt canh canl Wiring diagram
This page shows the only wiring diagram for the component.batt canh canl, which is found in the car Mitsubishi Outlander III (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram batt canh canl (1 of 1)
8 C-26
BATT CANH CANL
BLK WIRE
BLU WIRE
C-17 PNK WIRE
C-411
C-415
CAN DRIVE CIRCUIT
CAN TRANSCEIVER CIRCUIT
COMBINATION METER
COMPUTER DATA LINES SYSTEM
D-48-1
D-48-1 OCCUPANT CLASSIFI- CATION ECU
D-48-2
DR STPS GND D-34-2
DR STPS GND GND
ETACS-ECU (LEFT END OF DASH)
FUSE 17
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INTERFACE CIRCUIT
J/C
LCD (SRS)
LED DRIVE CIRCUIT
LEFT FRONT WEIGHT SENSOR
LEFT REAR WEIGHT SENSOR
NCA WIRE
PNK WIRE
RED WIRE
RIGHT FRONT WEIGHT SENSOR
RIGHT REAR WEIGHT SENSOR
SEAT SLIDE SENSOR (UNDER DRIVER'S SEAT)
SRS IND
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (3 of 4) -> BATT CANH CANL
