Mitsubishi Outlander III (2012-2015) 24 c-113 81 Wiring diagram
This page shows the only wiring diagram for the component.24 c-113 81, which is found in the car Mitsubishi Outlander III (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 24 c-113 81 (1 of 1)
1 G-02
10 A-17
21 C-101
24 C-113 81
86 C-109
9 C-118
9 C-17
A-17
BACKUP LIGHT SWITCH (LEFT SIDE OF TRANSMISSION)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
C-28
C-403
C-412
C-413
C-417
CVT
ETACS-ECU (LEFT END OF DASH)
FUSE 18
FUSE 7
GRN WIRE
GROUNDING CONNECTOR (C-01)
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
M/T
MULTIVISION DISPLAY
NCA WIRE
ORG/ WIRE
PNK WIRE
REAR VIEW CAMERA (CENTER OF LIFTGATE)
RED WIRE
RED/BLK WIRE
RELAY ENERGIZED
TRANSMISSION RANGE SWITCH (TOP OF TRANSAXLE)
TRANSMISSIONS SYSTEM
VIO WIRE
WHT WIRE
YEL WIRE
YEL/VIO WIRE
Go to component -> Rear view camera circuit, with multi-communication system -> 24 C-113 81
