Power top/sunroof circuit for Mitsubishi Outlander II facelift (2009-2013)

Power top/sunroof circuit

Get access

BLK WIRE BLK/WHT WIRE BLU WIRE C-316 C-317 C-36 CLOSE/ DOWN OPEN DRIVE CIRCUIT ETACS-ECU (LEFT SIDE OF DASH) FUSE 12 FUSE 15 GRN WIRE HALL SENSOR HOT AT ALL TIMES HOT W/ INPUT CIRCUIT LIN DRIVE CIRCUIT INTERFACE CIRCUIT OFF OFF UP SUNROOF MOTOR SUNROOF MOTOR ASSEMBLY (CENTER FRONT OF ROOF) SUNROOF SWITCH VIO WIRE YEL WIRE
