Mitsubishi Outlander II facelift (2009-2013) yel red/ Wiring diagram
This page shows the only wiring diagram for the component.yel red/, which is found in the car Mitsubishi Outlander II facelift (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram yel red/ (1 of 1)
1 C-301
13 6 10 4 C-312 HEAD RELAY (HI)
16 C-313
5 C-317
7 3 C-304
7 C-301
ANTI-THEFT SYSTEM
BEAM IND FOG IND
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
C-22
C-36
CAN DRIVE CIRCUIT
CAN TRANSCEIVER CIRCUIT
CIRCUIT LIN DRIVE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DAYTIME RUNNING LIGHT RELAY
DRL RELAY FOG RELAY
ETACS-ECU (BEHIND LEFT SIDE OF DASH)
FOG LIGHT RELAY
FUSE 1
FUSE 12
FUSE 13
FUSE 14 FUSE 15
FUSE 17 FUSE 16
FUSE 8
FUSIBLE LINK 36
FUSIBLE LINK BOX (ON POSITIVE TERMINAL ON BATTERY)
GRN WIRE
HEADLIGHT BACKUP CIRCUIT
HEADLIGHT RELAY (HIGH)
HEADLIGHT RELAY (LOW)
HOT AT ALL TIMES
INTERFACE CIRCUIT
LED DRIVE CIRCUIT
LIGHTING CONTROL SENSOR (W/ AUTOMATIC LIGHT) (TOP OF WINDSHIELD)
LT BLU WIRE
LT GRN WIRE
ORG/WHT WIRE
PARKING BRAKE SWITCH (AT BASE OF PARKING BRAKE LEVER)
PNK WIRE
POWER WINDOWS SYSTEM
RED/BLK WIRE
RELAY BOX (LEFT SIDE OF ENGINE COMPT)
RELAY ENERGIZED
TAILLIGHT CONTROL CIRCUIT
VIO WIRE
WHT WIRE
YEL RED/ WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Headlights circuit, with high intensity discharge (1 of 2) -> YEL RED/ WIRE
