Mitsubishi Outlander II facelift (2009-2013) right rear power window switch off Wiring diagram
This page shows the only wiring diagram for the component.right rear power window switch off, which is found in the car Mitsubishi Outlander II facelift (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear power window switch off (1 of 1)
ANTI-THEFT, HEADLIGHTS, EXTERIOR LIGHTS, INTERIOR LIGHTS, WIPER/WASHER SYSTEMS
AUTO DOWN DOWN
AUTO UP UP LEFT FRONT POWER WINDOW SWITCH
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
DOOR LOCKS SYSTEM
DOWN
DOWN UP
DOWN UP E-06
E-06 FRONT POWER WINDOW SUB SWITCH OFF
ETACS-ECU (BEHIND LEFT SIDE OF DASH)
FUSE 20
FUSE 8
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
ILL
INTERFACE CIRCUIT
LEFT FRONT DOOR SWITCH (IN LEFT "B" PILLAR)
LEFT FRONT POWER WINDOW MOTOR (IN LEFT FRONT DOOR)
LEFT REAR POWER OFF ON WINDOW SUB DOWN SWITCH
LEFT REAR POWER WINDOW MOTOR (IN LEFT REAR DOOR)
LEFT REAR POWER WINDOW SWITCH
LIN DRIVE CIRCUIT
LOCK LOCK SWITCH
LOCK UN- LOCK
OFF
OFF ON
OFF ON ON
OFF WINDOW SUB SWITCH
ORG/ WIRE
POWER WINDOW MAIN SWITCH (IN DRIVER'S DOOR POWER WINDOW MAIN SWITCH ASSEMBLY)
POWER WINDOW RELAY
RED WIRE
RIGHT FRONT POWER WINDOW MOTOR (IN RIGHT FRONT DOOR)
RIGHT FRONT POWER WINDOW SWITCH OFF
RIGHT REAR POWER
RIGHT REAR POWER WINDOW MOTOR (IN RIGHT REAR DOOR)
RIGHT REAR POWER WINDOW SWITCH OFF
UP UN LOCK
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power windows circuit -> RIGHT REAR POWER WINDOW SWITCH OFF
