Mitsubishi Outlander II facelift (2009-2013) headlight control unit Wiring diagram
This page shows the only wiring diagram for the component.headlight control unit, which is found in the car Mitsubishi Outlander II facelift (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram headlight control unit (1 of 1)
A-46
ASSEMBLY
AUTO SWITCH (W/ AUTOMATIC LIGHT)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
COLUMN ECU
COLUMN SWITCH
DIMMER PASSING SWITCH SWITCH
FOG LIGHTING SWITCH
HEAD LIGHTING SWITCH
HEADLIGHT CONTROL UNIT
HI LO OFF
LEFT DAYTIME RUNNING LIGHT HEADLIGHT ASSEMBLY
LEFT FOG LIGHT
LEFT HEADLIGHT ASSEMBLY
LIGHTING SWITCH
LT BLU WIRE
LT GRN WIRE
NCA WIRE
OFF
ON OFF
ORG/WHT WIRE
PASS ON
PNK WIRE
REAR OF ENGINE COMPT)
RED/BLK WIRE
RIGHT DAYTIME RUNNING LIGHT HEADLIGHT ASSEMBLY
RIGHT FOG LIGHT
RIGHT HEADLIGHT
TAIL LIGHTING SWITCH
VIO WIRE
Go to component -> Headlights circuit, with high intensity discharge (2 of 2) -> HEADLIGHT CONTROL UNIT
