Mitsubishi Outlander II facelift (2009-2013) front dome light Wiring diagram
This page shows the only wiring diagram for the component.front dome light, which is found in the car Mitsubishi Outlander II facelift (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front dome light (1 of 1)
BLK WIRE
BLK/WHT WIRE
BRN WIRE
C-103
CAN TRANSCEIVER CIRCUIT
COMBINATION METER
DOOR
FRONT DOME LIGHT
FUSE 24
GRN WIRE
HOT AT ALL TIMES
JOINT CONNECTOR
LCD (EACH DOOR)
LEFT FOOT LIGHT
LEFT VANITY MIRROR LIGHT
LIGHT FOOT
LIMIT SWITCH
NCA WIRE
OFF
OFF ON
ON OFF
PASSENGER COMPARTMENT RELAY BOX
PNK WIRE
REAR DOME LIGHT
RED/BLK WIRE
RED/WHT WIRE
RIGHT FOOT LIGHT
RIGHT VANITY MIRROR LIGHT
SWITCH LIMIT
TIMER RELAY
YEL WIRE
YEL/GRN WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> FRONT DOME LIGHT
