Mitsubishi Outlander II facelift (2009-2013) fog lighting switch Wiring diagrams
This page contains all the electrical diagrams for the component. fog lighting switch, in which he is found in the car Mitsubishi Outlander II facelift (2009-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
fog lighting switch wiring diagram (1 of 2)
A-46
ASSEMBLY
AUTO SWITCH (W/ AUTOMATIC LIGHT)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
COLUMN ECU
COLUMN SWITCH
DIMMER PASSING SWITCH SWITCH
FOG LIGHTING SWITCH
HEAD LIGHTING SWITCH
HEADLIGHT CONTROL UNIT
HI LO OFF
LEFT DAYTIME RUNNING LIGHT HEADLIGHT ASSEMBLY
LEFT FOG LIGHT
LEFT HEADLIGHT ASSEMBLY
LIGHTING SWITCH
LT BLU WIRE
LT GRN WIRE
NCA WIRE
OFF
ON OFF
ORG/WHT WIRE
PASS ON
PNK WIRE
REAR OF ENGINE COMPT)
RED/BLK WIRE
RIGHT DAYTIME RUNNING LIGHT HEADLIGHT ASSEMBLY
RIGHT FOG LIGHT
RIGHT HEADLIGHT
TAIL LIGHTING SWITCH
VIO WIRE
Go to component -> Headlights circuit, with high intensity discharge (2 of 2) -> FOG LIGHTING SWITCH
fog lighting switch wiring diagram (2 of 2)
2 A-46
3 4 5 PNK WIRE
3.0L W/ ASC
3.0L W/O ASC, 2.4L
BLK WIRE
BLK/WHT WIRE
BRN WIRE
C-131
C-34
COLUMN ECU
COLUMN SWITCH
DIMMER SWITCH
FOG LIGHTING SWITCH
HEAD LIGHTING SWITCH
HI LO
LEFT FOG LIGHT
LEFT HEADLIGHT ASSEMBLY
LIGHTING SWITCH
LT BLU WIRE
LT GRN WIRE
NCA WIRE
OFF ON
ON OFF
ON OFF LO
ORG/ WIRE
PASS OFF
PASSING SWITCH
PNK WIRE
REAR OF ENGINE COMPT)
RED/BLK WIRE
RIGHT FOG LIGHT
RIGHT HEADLIGHT ASSEMBLY
TAIL LIGHTING AUTO SWITCH SWITCH (W/ AUTOMATIC LIGHT)
VIO WIRE
Go to component -> Headlights circuit, without high intensity discharge (2 of 2) -> FOG LIGHTING SWITCH
