Mitsubishi Outlander II facelift (2009-2013) dimmer switch Wiring diagram
This page shows the only wiring diagram for the component.dimmer switch, which is found in the car Mitsubishi Outlander II facelift (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dimmer switch (1 of 1)
2 A-46
3 4 5 PNK WIRE
3.0L W/ ASC
3.0L W/O ASC, 2.4L
BLK WIRE
BLK/WHT WIRE
BRN WIRE
C-131
C-34
COLUMN ECU
COLUMN SWITCH
DIMMER SWITCH
FOG LIGHTING SWITCH
HEAD LIGHTING SWITCH
HI LO
LEFT FOG LIGHT
LEFT HEADLIGHT ASSEMBLY
LIGHTING SWITCH
LT BLU WIRE
LT GRN WIRE
NCA WIRE
OFF ON
ON OFF
ON OFF LO
ORG/ WIRE
PASS OFF
PASSING SWITCH
PNK WIRE
REAR OF ENGINE COMPT)
RED/BLK WIRE
RIGHT FOG LIGHT
RIGHT HEADLIGHT ASSEMBLY
TAIL LIGHTING AUTO SWITCH SWITCH (W/ AUTOMATIC LIGHT)
VIO WIRE
Go to component -> Headlights circuit, without high intensity discharge (2 of 2) -> DIMMER SWITCH
