Mitsubishi Outlander II facelift (2009-2013) condenser fan relay Wiring diagram
This page shows the only wiring diagram for the component.condenser fan relay, which is found in the car Mitsubishi Outlander II facelift (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram condenser fan relay (1 of 1)
A-13
A/C COMPRESSOR ASSEMBLY (LEFT FRONT OF ENGINE)
A/C COMPRESSOR CLUTCH
A/C COMPRESSOR RELAY
A/C PRESSURE SENSOR (RIGHT FRONT OF ENGINE COMPT)
A/C REFRIGERANT TEMPERATURE SWITCH
AIR THERMO SENSOR (BEHIND RIGHT SIDE OF DASH, ON HVAC UNIT)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
C-05
C-33
CONDENSER FAN RELAY
ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT)
FAN CONTROL RELAY
FUSE 7
FUSIBLE LINK 28
FUSIBLE LINK 29
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INTERIOR TEMPERATURE SENSOR (BEHIND LEFT SIDE OF DASH)
LT GRN WIRE
NCA WIRE
ON OFF
ORG/ WIRE
POWER TRANSISTOR (NEAR BLOWER MOTOR)
RADIATOR FAN RELAY
RED WIRE
RED/WHT WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/PNK WIRE
YEL/VIO WIRE
Go to component: -> 2.4l, automatic a/c circuit (2 of 3) -> CONDENSER FAN RELAY
