Mitsubishi Outlander II facelift (2009-2013) blower speed selection dial Wiring diagrams

This page contains all the electrical diagrams for the component. blower speed selection dial, in which he is found in the car Mitsubishi Outlander II facelift (2009-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram blower speed selection dial (1 of 2)

Wiring diagram blower speed selection dial for Mitsubishi Outlander II facelift (2009-2013)

Get access

A/C CONTROL PANEL A/C SWITCH A/C SWITCH IND B-10 B-11 BACK LIGHT BLK WIRE BLK/WHT WIRE BLOWER SPEED SELECTION DIAL BLU WIRE COMPUTER DATA LINES SYSTEM CONDENSER FAN MOTOR (LEFT FRONT OF ENGINE COMPT) ENGINE CONTROL MODULE ENGINE COOLANT TEMPERATURE SENSOR (TOP REAR OF ENGINE) GRN/RED WIRE GRN/WHT WIRE GRY WIRE INTERFACE CIRCUIT MODE SELECTION DIAL OFF ON OUTSIDE/ INSIDE AIR SELECTION SWITCH ORG/ WIRE OUTSIDE/ INSIDE AIR SELECTION IND PNK WIRE POWER SUPPLY RADIATOR FAN MOTOR (CENTER FRONT OF ENGINE COMPT) REAR WINDOW DEFOGGER IND REAR WINDOW DEFOGGER SWITCH RED/WHT WIRE RED/YEL WIRE TEMPERATURE CONTROL DIAL YEL/GRN WIRE

Go to component: -> 2.4l, automatic a/c circuit (3 of 3) -> BLOWER SPEED SELECTION DIAL

Wiring diagram blower speed selection dial (2 of 2)

Wiring diagram blower speed selection dial for Mitsubishi Outlander II facelift (2009-2013)

Get access

A/C CONTROL PANEL A/C SWITCH A/C SWITCH IND B-10 B-11 BACK LIGHT BLK WIRE BLK/WHT WIRE BLOWER SPEED SELECTION DIAL BLU WIRE COMPUTER DATA LINES SYSTEM CONDENSER FAN MOTOR (LEFT FRONT OF ENGINE COMPT) ENGINE CONTROL MODULE ENGINE COOLANT TEMPERATURE SENSOR (TOP REAR OF ENGINE) GRN/RED WIRE GRN/WHT WIRE INTERFACE CIRCUIT MODE SELECTION DIAL OFF ON OUTSIDE/ INSIDE AIR SELECTION SWITCH ORG/ WIRE OUTSIDE/ INSIDE AIR SELECTION IND PNK WIRE POWER SUPPLY RADIATOR FAN MOTOR (CENTER FRONT OF ENGINE COMPT) REAR WINDOW DEFOGGER IND REAR WINDOW DEFOGGER SWITCH RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE TEMPERATURE CONTROL DIAL YEL/BLU WIRE YEL/GRN WIRE

Go to component: -> 3.0l, automatic a/c circuit (3 of 3) -> BLOWER SPEED SELECTION DIAL
