Immobilizer circuit for Mitsubishi Outlander II (2005-2009)

90 B-11 BLK WIRE BLK/WHT WIRE BRN WIRE C-307 C-317 COMPUTER DATA LINES SYSTEM ENGINE COMPARTMENT RELAY BOX ENGINE CONTROL MODULE (LEFT REAR CORNER OF ENGINE COMPT) ENGINE CONTROLS SYSTEM ETACS-ECU (BEHIND LEFT SIDE OF DASH) FUSE 12 FUSE 21 FUSE 30 FUSE 8 GRN/RED WIRE GRY WIRE HOT AT ALL TIMES ID CODE (TRANSPONDER) IGNITION KEY RING ANTENNA KOS-ECU (W/ KEYLESS ENTRY) (BEHIND LEFT SIDE OF DASH) LT GRN WIRE MFI RELAY NCA WIRE PNK WIRE RECEIVER ANTENNA MODULE (NEAR IGNITION SWITCH) RED WIRE RELAY ENERGIZED VIO WIRE WHT WIRE WHT/BLU WIRE WHT/RED WIRE WIRELESS CONTROL MODULE (W/O KEYLESS ENTRY) (NEAR IGNITION SWITCH) YEL WIRE YEL/GRN WIRE YEL/GRY WIRE
