Mitsubishi Outlander II (2005-2009) fusible link 26 Wiring diagram
This page shows the only wiring diagram for the component.fusible link 26, which is found in the car Mitsubishi Outlander II (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fusible link 26 (1 of 1)
ASC-ECU
BLK WIRE
BLK/WHT WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
ENGINE COMPARTMENT RELAY BOX (ON LEFT SIDE OF ENGINE COMPT)
FUSIBLE LINK 26
FUSIBLE LINK 27
GRN WIRE
HOT AT ALL TIMES
HYDRAULIC UNIT
LEFT FRONT WHEEL SPEED SENSOR (AT LEFT FRONT WHEEL HUB ASSEMBLY)
LEFT REAR WHEEL SPEED SENSOR (AT LEFT REAR WHEEL HUB ASSEMBLY)
LT BLU WIRE
MOTOR
NCA WIRE
ORG/ WIRE
PNK WIRE
RED/BLK WIRE
RIGHT FRONT WHEEL SPEED SENSOR (AT RIGHT FRONT WHEEL HUB ASSEMBLY)
RIGHT REAR WHEEL SPEED SENSOR (AT RIGHT REAR WHEEL HUB ASSEMBLY)
SOLENOID VALVE
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Anti-lock brakes circuit, with active skid control (1 of 2) -> FUSIBLE LINK 26
