Exterior lamps circuit for Mitsubishi Outlander I (2002-2009)

BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BRN WIRE C-301 C-304 C-311 C-312 C-313 CRUISE CONTROL SYSTEM ETACS-ECU (BEHIND LEFT SIDE OF DASH) FUSE 10 FUSE 18 FUSE 2 GRN WIRE GRN/RED WIRE HIGH MOUNTED STOPLIGHT HOT AT ALL TIMES LEFT HEADLIGHT ASSEMBLY LEFT LICENSE PLATE LIGHT LEFT REAR COMBINATION LIGHT LEFT REAR SIDE MARKER LIGHT LEFT SIDE TURN SIGNAL LIGHT LT BLU WIRE NCA WIRE PNK WIRE RED WIRE RELAY ENERGIZED RIGHT HEADLIGHT ASSEMBLY RIGHT LICENSE PLATE LIGHT RIGHT REAR COMBINATION LIGHT RIGHT REAR SIDE MARKER LIGHT RIGHT SIDE TURN SIGNAL LIGHT SPARE CONNECTOR SWITCH BOX (BEHIND RIGHT REAR QUARTERPANEL) STOPLIGHT SWITCH (ABOVE BRAKE PEDAL, ON BRACKET) TAILLIGHT CONTROL CIRCUIT TURN SIGNAL LIGHT CONTROL CIRCUIT VIO WIRE WHT WIRE YEL WIRE

BLK WIRE BLK/WHT WIRE BRN WIRE C-301 C-317 CAN DRIVE CIRCUIT CAN TRANSCEIVER CIRCUIT CENTER PANEL UNIT COLUMN ECU COLUMN SWITCH COMBINATION METER COMPUTER DATA LINES SYSTEM ETACS-ECU (BEHIND LEFT SIDE OF DASH) FUSE 12 FUSE 8 GRN WIRE HAZARD WARNING SWITCH HEAD LIGHTING SWITCH HEADLIGHT, FAN BACKUP CIRCUIT HOT AT ALL TIMES INTERFACE CIRCUIT LED DRIVE CIRCUIT LEFT TURN IND LIN DRIVE CIRCUIT INTERFACE CIRCUIT PNK WIRE POWER WINDOWS SYSTEM RED/BLK WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT TURN IND RIGHT TURN SIGNAL LIGHT SWITCH TAIL IND TAIL LIGHTING SWITCH LEFT TURN- SIGNAL LIGHT SWITCH VIO WIRE YEL/GRN WIRE
