Mitsubishi Outlander I (2002-2009) Anti-lock brakes circuit, with active skid control

ASC-ECU BLK WIRE BLK/WHT WIRE BLU WIRE COMPUTER DATA LINES SYSTEM ENGINE COMPARTMENT RELAY BOX (ON LEFT SIDE OF ENGINE COMPT) FUSIBLE LINK 26 FUSIBLE LINK 27 GRN WIRE HOT AT ALL TIMES HYDRAULIC UNIT LEFT FRONT WHEEL SPEED SENSOR (AT LEFT FRONT WHEEL HUB ASSEMBLY) LEFT REAR WHEEL SPEED SENSOR (AT LEFT REAR WHEEL HUB ASSEMBLY) LT BLU WIRE MOTOR NCA WIRE ORG/ WIRE PNK WIRE RED/BLK WIRE RIGHT FRONT WHEEL SPEED SENSOR (AT RIGHT FRONT WHEEL HUB ASSEMBLY) RIGHT REAR WHEEL SPEED SENSOR (AT RIGHT REAR WHEEL HUB ASSEMBLY) SOLENOID VALVE VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE YEL/GRN WIRE

ABS IND. ANALOG INTERFACE CIRCUIT ASC OFF SWITCH BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BRN WIRE C-301 C-304 C-312 C-313 C-317 CAN DRIVE CIRCUIT COMBINATION METER COMPUTER DATA LINES SYSTEM ETACS-ECU (BEHIND FUSE 12 FUSE 2 FUSE 9 G, YAW RATE SENSOR (UNDER FRONT OF CENTER FLOOR CONSOLE) GRN WIRE GRN/WHT WIRE HOT AT ALL TIMES ILLUM INTERFACE CIRCUIT LED DRIVE CIRCUIT ORG/ WIRE PNK WIRE RED WIRE RED/BLK WIRE RED/WHT WIRE RELAY ENERGIZED STEERING WHEEL SENSOR (TOP OF STEERING COLUMN) STOPLIGHT SWITCH (ABOVE BRAKE PEDAL, ON BRACKET) WHT/BLK WIRE WHT/RED WIRE YEL/GRN WIRE
