Mitsubishi Outlander I (2002-2009) vio Wiring diagrams
This page contains all the electrical diagrams for the component. vio, in which he is found in the car Mitsubishi Outlander I (2002-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram vio (41 of 42)
BLK WIRE
BLU WIRE
BRN WIRE
COLUMN ECU
COLUMN SWITCH
ETACS-ECU (BEHIND LEFT SIDE OF DASH)
FAST
FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INTERFACE CIRCUIT
INTERMITTENT WIPER INTERVAL ADJUSTING KNOB
LIN DRIVE CIRCUIT
MIST
OFF
POWER WINDOWS SYSTEM
REAR WINDOW WASHER RELAY
RED WIRE
RELAY
RELAY 3
SHIELD WIND-
SLOW
SWITCH WASHER WINDSHIELD
VIO WIRE
WASH
WASHER MOTOR (ON WASHER FLUID RESERVOIR)
WHT WIRE
WINDSHIELD WASHER RELAY
WINDSHIELD WIPER AUTOMATIC STOP RELAY
WINDSHIELD WIPER MOTOR (LEFT REAR OF ENGINE COMPT)
WINDSHIELD WIPER SPEED SWITCHING RELAY
WIPER SWITCH
YEL WIRE
Go to component -> Front wiper/washer circuit -> VIO WIRE
Wiring diagram vio (42 of 42)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
COLUMN ECU
COLUMN SWITCH
COMPUTER DATA LINES SYSTEM
ETACS-ECU (BEHIND
FUSE
FUSE FUSE
HOT AT ALL TIMES
INTERFACE CIRCUIT
LIN DRIVE CIRCUIT
LT BLU WIRE
OFF
ON REAR WIPER SWITCH
ORG/ WIRE
POWER WINDOWS SYSTEM
REAR WASHER SWITCH
REAR WINDOW WASHER RELAY
REAR WIPER MOTOR (CENTER OF LIFTGATE)
REAR WIPER RELAY
RED WIRE
RELAY
RELAY 3
TRANSMISSION CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
TRANSMISSION RANGE SWITCH (TOP OF TRANSAXLE)
VIO WIRE
WASHER MOTOR (ON WASHER FLUID RESERVOIR)
WHT WIRE
WINDSHIELD WASHER RELAY
Go to component -> Rear washer/wiper circuit -> VIO WIRE
