Mitsubishi Outlander I (2002-2009) right turn signal light switch wiring diagram
This page shows the only wiring diagram for the component.right turn signal light switch, which is found in the car Mitsubishi Outlander I (2002-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
right turn signal light switch wiring diagram (1 of 1)
BLK WIRE
BLK/WHT WIRE
BRN WIRE
C-301
C-317
CAN DRIVE CIRCUIT
CAN TRANSCEIVER CIRCUIT
CENTER PANEL UNIT
COLUMN ECU
COLUMN SWITCH
COMBINATION METER
COMPUTER DATA LINES SYSTEM
ETACS-ECU (BEHIND LEFT SIDE OF DASH)
FUSE 12
FUSE 8
GRN WIRE
HAZARD WARNING SWITCH
HEAD LIGHTING SWITCH
HEADLIGHT, FAN BACKUP CIRCUIT
HOT AT ALL TIMES
INTERFACE CIRCUIT
LED DRIVE CIRCUIT
LEFT TURN IND
LIN DRIVE CIRCUIT INTERFACE CIRCUIT
PNK WIRE
POWER WINDOWS SYSTEM
RED/BLK WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT TURN IND
RIGHT TURN SIGNAL LIGHT SWITCH
TAIL IND
TAIL LIGHTING SWITCH LEFT TURN- SIGNAL LIGHT SWITCH
VIO WIRE
YEL/GRN WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> RIGHT TURN SIGNAL LIGHT SWITCH
