Mitsubishi Outlander I (2002-2009) radio, cd player or cd changer Wiring diagrams
This page contains all the electrical diagrams for the component. radio, cd player or cd changer, in which he is found in the car Mitsubishi Outlander I (2002-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram radio, cd player or cd changer (1 of 3)
1 5 D-06
10 C-10 25 C-09
5 10 PNK WIRE
A/C CONTROL PANEL
ASC OFF SWITCH
AUDIO VISUAL NAVIGATION UNIT
AUTO-CRUISE CONTROL SWITCH
BLK WIRE
BLK/WHT WIRE
BRN WIRE
C-202 CLOCK SPRING (UNDER STEERING WHEEL)
C-204
C-311
C-315
C-317
CENTER PANEL UNIT
COLUMN ECU
COLUMN SWITCH
COMBINATION METER
COURTESY LAMPS CIRCUIT
DRIVE MODE SELECTOR
ETACS-ECU (BEHIND LEFT SIDE OF DASH)
FUSE 12
FUSE 20 FUSE 8
FUSE 9
GRN/WHT WIRE
GRY WIRE
HEAD
HEATED SEAT SWITCH
HOT AT ALL TIMES
INTERFACE CIRCUIT
KEY REMINDER SWITCH IGNITION KEY HOLE ILLUMINATION LIGHT
LED DRIVE CIRCUIT
LIGHTING SWITCH
NCA WIRE
PNK WIRE
POWER WINDOW MAIN SWITCH
RADIO, CD PLAYER OR CD CHANGER
REAR DISPLAY SPARE CONNECTOR (IN LEFT "C" PILLAR)
REAR DISPLAY UNIT
RED/WHT WIRE
RED/YEL WIRE
RELAY ENERGIZED
RHEOSTAT
RIGHT HEATED SEAT
SHIFT SWITCH ASSEMBLY
STEERING AUDIO SWITCH
STEERING VOICE CONTROL SWITCH
TAIL
TAILLIGHT CONTROL CIRCUIT
VIO WIRE
WHT WIRE
YEL/VIO WIRE
Go to component -> Instrument illumination circuit -> RADIO, CD PLAYER OR CD CHANGER
Wiring diagram radio, cd player or cd changer (2 of 3)
Go to component -> Navigation circuit, without rear entertainment -> RADIO, CD PLAYER OR CD CHANGER
Wiring diagram radio, cd player or cd changer (3 of 3)
ANTENNA AMPLIFIER
AUDIO SWITCH PANEL
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
C-202
C-204
C-315
C-317
CENTER PANEL UNIT
CH UP CH DN VOL UP
CLOCK SPRING (C-204: UNDER STEERING WHEEL)
COMPUTER DATA LINES SYSTEM
ETACS-ECU (BEHIND LEFT SIDE OF DASH) FUSE 16
FUSE 7
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
HANDS FREE MODULE (BEHIND CENTER OF DASH)
HOT AT ALL TIMES
HOT W/ ACC RELAY 2 ENERGIZED
ILL
ILL ILL
LCD PANEL (AUDIO)
LEFT FRONT DOOR SPEAKER
LEFT REAR DOOR SPEAKER
LEFT TWEETER
NCA WIRE
ORG/ WIRE
PNK WIRE
RADIO, CD PLAYER OR CD CHANGER
RED WIRE
RED/WHT WIRE
RIGHT FRONT DOOR SPEAKER
RIGHT REAR DOOR SPEAKER
RIGHT TWEETER
ROOF ANTENNA
STEERING AUDIO SWITCH
VIO WIRE
VOL DN
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Radio circuit, without rear entertainment, without amplifier -> RADIO, CD PLAYER OR CD CHANGER
